European Single Girder Overhead Crane is designed with high configuration, which is developed with advanced design technology referring to European FEM standard. Cranes are mainly made up by single main beams, end beams, hoist, electrical parts and other
Electric single girder European Hoist Type Overhead Crane could be widely used to handle materials in many industries' workshop and warehouse. Such as machinery manufacture, warehouse, logistic, food, paper making, electronics industries workshop and other material handling situations.
40+ YEARS OF EXPERIENCE
CHINA FACTORY DIRECT SALE.
EXPORT TO 160+ COUNTRIES
On May 7th, 2016, European single girder overhead crane has finished installation within 7 days in Philippines.
The Philippines customers plan to invest a European single girder overhead crane. After comparing the manufacturers and understanding the performance of products, they chose to sign an order with us.
In order to serve customers better, JUREN always provides installation guidance services. The company sent experienced technicians to assist in the installation and commissioning of the European single girder overhead crane, ensuring its safe and stable operation.
5t European single girder overhead crane installations for the Saudi Electricity Company
Get Free Quote
3 ton European single girder overhead crane installation in shipyard Maldives
Get Free QuoteThe lifting hoist adopts M5 working class with double lifting speed. motor with ABM German brand motor. Travelling motor uses SEW European brand in one motor gear motors. Cross and long traveling are variable travelling speed. Electric parts adopt Siemens brand. The protection class is IP 54 high class. The working class can reach to A5/M5 class under ISO standard.
Less expensive due to a simpler trolley design, reduced freight costs, simplified and faster installation, and less material for the bridge and runway beams.
Most economical option for light to medium-duty cranes.
Lower loads on the building structure or foundations due to a reduced deadweight. In many cases, it can be supported by existing roof structure without the use of additional support columns.
Better hook approach for both trolley travel and bridge travel Easier to install, service, and maintain
Ideal for workshops, warehouses, material yards, and manufacturing and production facilities
Lighter load on runway rails or beams means less wear on the beams and end truck wheels over time
Great for facilities with low headroom
| Lifting Capacity (t) | Span (m) | Lifting Height (m) | Lifting Speed (m/min) | Hoist Traveling Speed(m/min) | Crane Traveling Speed (m/min) | Recommanded Track | ||
| 1 | 7.5~31.5 | 6~12 | 0.8/5 | 2~20 | 3~30 | P24 | ||
| 2 | 6~12 | 0.8/5 | 2~20 | 3~30 | P24 | |||
| 3.2 | 6~12 | 0.8/5 | 2~20 | 3~30 | P24 | |||
| 5 | 6~12 | 0.8/5 | 2~20 | 3~30 | P24、P30 | |||
| 10 | 6~12 | 0.8/5 | 2~20 | 3~30 | P30 | |||
| 12.5 | 6~12 | 0.66/4 | 2~20 | 3~30 | P30 | |||
| 16 | 9~12 | 0.66/4 | 2~20 | 3~30 | P43 | |||
| 20 | 9~12 | 0.66/4 | 2~20 | 3~30 | P43 | |||
| 30 | 9~28.5 | 0.66/4 | 2~20 | 3~30 | P43 | |||
| Work Duty | A3,A4,A5 | |||||||
| Power | 380V, 50Hz or Other | |||||||
| Temperature of Working Environment | ﹣20℃~﹢40℃ | |||||||
Capacity : 5-100t Span : 5~31.5m Lifting height ： 6~30m Work level : A4,A5,A6,A7,A8
Capacity : 50t - 800t Span : 5~31.5m Lifting height ： 6~30m Work level : A4, A5,A6,A7
Capacity : 5-1000t Span : 5~31.5m Lifting height ： 6~30m Work level : A6,A7,A8
